The Calutron Secret: How WWII Engineers Used 14,700 Tons of Treasury Silver for Uranium Separation

On August 3rd, 1942, a seemingly outrageous request echoed through the halls of the United States Treasury Building in Washington, D.C.

Lieutenant Colonel Kenneth Nicholls entered the office of Under Secretary of the Treasury Daniel Bell with a pressing need for an unprecedented amount of metal—6,000 tons of silver.

This request was not for minting coins or bolstering reserves; it was for a classified project that could potentially alter the course of World War II.

When asked how many Troy ounces that amounted to, Nicholls found himself at a loss, and so did Bell.

The absurdity of the moment hung in the air as Nicholls insisted on the necessity of the quantity without understanding the conversion.

thumbnail

Bell, however, was unyielding; “Young man, you may think of silver in tons, but the Treasury will always think of silver in troy ounces.”

What Nicholls was unable to disclose was the true purpose behind this colossal request.

The silver was to aid in the construction of a machine designed to separate uranium isotopes—a critical step in the development of the world’s first atomic bomb.

Ultimately, the amount of silver needed would not be just 6,000 tons; it would balloon to an astonishing 14,700 tons, valued at over $300 million in 1942—a staggering sum equivalent to nearly $6 billion today.

This is the story of the Calutron, a brilliant yet desperate solution to one of the most formidable challenges faced by the Manhattan Project: how to separate uranium-235 from uranium-238 when they are almost chemically identical.

To grasp the magnitude of this challenge, we must first understand the significance of uranium-235.

When a neutron strikes a uranium-235 nucleus, it splits apart, releasing an immense amount of energy and additional neutrons, which in turn can split more atoms, creating a chain reaction.

This principle is the foundation of the atomic bomb.

However, natural uranium contains only 0.72% uranium-235, while the remainder is predominantly uranium-238, which cannot sustain a chain reaction.

To produce a bomb, uranium must be enriched to at least 90% uranium-235.

The task at hand was to separate these two isotopes, which have the same number of protons, electrons, and chemical properties—differing only by three neutrons.

Various methods were explored for uranium separation, including gaseous diffusion, thermal diffusion, and centrifuges, but each approach faced significant technical hurdles and uncertainties in their effectiveness within the timeline of the war.

It was then that physicist Ernest Lawrence, who was working at the University of California, Berkeley, proposed a novel idea: electromagnetic separation.

Inspired by discussions with British physicist Mark Oliphant about Britain’s atomic research, Lawrence envisioned using magnetism to separate uranium isotopes.

The principle was deceptively simple.

By ionizing uranium and giving it an electric charge, the ions could be propelled through a powerful magnetic field.

The magnetic field would deflect the ions based on their mass, allowing the heavier uranium-238 ions to curve less and the lighter uranium-235 ions to curve more.

This process was essentially a mass spectrometer scaled up to industrial levels.

Lawrence converted his old 37-inch cyclotron into the first prototype, aptly named the Calutron, short for California University Cyclotron.

On December 2nd, 1941, just days before the attack on Pearl Harbor, the Calutron was activated for the first time.

It worked.

A uranium beam intensity of 5 microamperes reached the collector, confirming Lawrence’s hypothesis.

By January 1942, they had produced 18 micrograms of uranium enriched to 25%, a tenfold increase over previous methods.

However, the leap from laboratory success to producing sufficient quantities of weapons-grade uranium was daunting.

The Manhattan Project required kilograms of enriched uranium, necessitating the construction of massive Calutrons—hundreds of them—each requiring enormous magnets made from highly conductive materials.

By mid-1942, Colonel James Marshall, the chief engineer of the Manhattan Project, and his deputy, Kenneth Nicholls, faced a harsh reality: to construct the electromagnetic separation plant, known as Y-12 at Oak Ridge, Tennessee, they would need 5,000 short tons of copper for the magnet windings.

However, World War II had created a severe shortage of copper due to its extensive use in electrical wiring for military equipment and infrastructure.

With copper in high demand, the Manhattan Project could not secure the necessary supply.

In search of alternatives, Nicholls and Marshall turned their attention to silver, the most electrically conductive element on Earth, even surpassing copper.

They determined that an 11 to 10 ratio meant that 11 parts of silver could replace 10 parts of copper.

To substitute the required 5,000 tons of copper, they would need approximately 5,500 tons of silver.

But where could they possibly acquire such an immense quantity of silver during wartime? The answer lay within the United States Treasury, which held vast reserves of silver bullion at the West Point Bullion Depository in New York.

On August 3rd, 1942, Nicholls approached Under Secretary Bell and explained, in as much detail as security allowed, the dire need for silver for a project of utmost national importance.

When Bell inquired about the quantity, Nicholls stated the need for 6,000 tons.

Stunned, Bell asked how many troy ounces that was.

The two men found themselves unable to convert tons to troy ounces, highlighting the absurdity of the situation.

Eventually, Bell agreed to the loan, but with strict conditions: the silver would be weighed to the troy ounce, monthly reports would be required, armed guards would accompany every shipment, and all silver would be returned at the end of the war.

As the Manhattan Project’s plans expanded, so did the demand for silver.

Ultimately, 14,700 short tons—equivalent to 13,300 metric tons and 430 million troy ounces—were borrowed from the Treasury.

At 1942 prices, this silver was worth over $300 million, making it one of the largest financial transactions in American history.

The government essentially loaned itself a fortune in silver to develop a weapon it was uncertain would succeed.

The silver arrived in 1,000 troy ounce bars, each weighing about 31 kilograms.

These bars were transported under armed guard by rail to the Defense Plant Corporation in Carteret, New Jersey, where they were melted down and cast into cylindrical billets.

These billets were then sent to Phelps Dodge in Bayway, New Jersey, where they were extruded under immense pressure into strips measuring 625 inches thick, 3 inches wide, and 40 feet long.

A total of 258 carloads of silver strips were shipped under guard to Alice Chalmers in Milwaukee, Wisconsin.

There, engineers wound the silver strips onto magnetic coils and sealed them into welded casings.

Each coil was massive, weighing tons, and designed to generate intense magnetic fields.

Afterward, the completed magnets traveled by unguarded flat cars to Oak Ridge, Tennessee.

The reason for shipping them unguarded was that they no longer resembled silver; they were encased in anonymous coverings that concealed their true nature.

Meanwhile, construction of the Y-12 electromagnetic plant was well underway, covering 825 acres in Bear Creek Valley.

This site was chosen due to the surrounding ridges, which could contain a potential explosion or nuclear accident.

The plant would eventually encompass nine major processing buildings and 200 support structures, covering nearly 80 acres of floor space.

The Calutrons were arranged in oval tracks, known as racetracks, when viewed from above.

Each racetrack housed multiple calutron tanks arranged in a circular formation.

Inside each tank, uranium tetrachloride was heated and ionized.

The resulting ions were accelerated through a vacuum chamber and deflected by 180 degrees by the massive silver-wound magnets.

The heavier uranium-238 ions curved less, while the lighter uranium-235 ions curved more, allowing them to strike different collectors.

The separated uranium was then chemically recovered and further processed.

However, transforming this concept into reality required solving numerous engineering challenges.

The vacuum tanks, each weighing 14 tons, frequently crept out of alignment due to magnetic forces, sometimes shifting as much as 3 inches.

They needed to be secured more firmly.

Moisture inside the magnet coils caused short circuits and rust, necessitating the disassembly, cleaning, and rewinding of magnets.

Debris, referred to as “gunk” and “crud,” accumulated inside the vacuum chambers, obstructing slits and causing ion beams to lose focus.

Despite their low intensity, the ion beams generated intense heat, capable of melting collectors after hours of operation.

Engineers implemented water cooling systems and developed procedures for cleaning equipment without contaminating the silver.

Special handling procedures were established for the silver itself.

Workers placed paper beneath drilling operations to catch every filing, and at the end of each shift, the paper was collected to recover the silver.

When machinery was dismantled for cleaning, every surface was wiped down, and even the floorboards beneath the equipment were eventually ripped up and burned to recover microscopic amounts of silver.

Kenneth Nicholls was responsible for providing monthly accounting reports to the Treasury, detailing every troy ounce of silver used.

The scrutiny was intense, and the responsibility was enormous.

The first alpha racetrack became operational in early 1944 after extensive debugging.

By the spring of 1944, multiple alpha and beta racetracks were running.

The beta racetracks took partially enriched uranium from the alpha racetracks and enriched it further, achieving the 90% purity required for weapons-grade material.

One remarkable aspect of the Y-12 plant was its workforce.

Tennessee Eastman, a chemical company, was hired to operate the facility and recruited thousands of workers, many from the rural areas surrounding Oak Ridge.

Most had only high school educations, and many were young women, some barely out of their teens.

These women became known as the “Calutron girls.”

They operated control panels in shifts covering 24 hours a day, monitoring dials, adjusting knobs, and ensuring the stability of the uranium ion beams.

The work required intense concentration and discipline, as a small fluctuation could ruin hours of effort.

Astonishingly, these young women had no idea what they were doing; for security reasons, they were told nothing about uranium, isotopes, or atomic bombs.

They were simply trained to follow procedures: keep the needles in the green zones, adjust knobs as needed, and refrain from asking questions.

As Kenneth Nichols later noted, they were trained like soldiers not to reason why, and they excelled at their tasks.

Initially, scientists from UC Berkeley operated the Calutrons to iron out bugs and establish operating procedures before handing control over to the Tennessee Eastman operators.

Nichols began comparing production data and noticed something startling: the young women operators were outproducing the PhD physicists.

Skeptical, Lawrence and Nichols agreed to a production race between the scientists and the “Hillbilly Girls.

” Lawrence lost.

The reason for this surprising outcome was straightforward: the scientists’ instincts compelled them to investigate fluctuations in the dials, leading to time spent analyzing and hypothesizing, while the young women simply made adjustments and moved on, keeping the machines running at peak efficiency.

This experience highlighted a profound lesson about the difference between understanding and execution.

The scientists understood the physics, while the young women executed the process effectively.

Years later, after the war had concluded and the atomic bombs were dropped on Hiroshima and Nagasaki, many of the Calutron girls learned for the first time what they had been doing.

They had been separating uranium-235, contributing to the construction of the atomic bomb.

Reactions varied; some felt pride, others horror, but all were astonished that the fate of the war had, in some small way, rested in their hands.

By July 1945, the Y-12 plant had produced sufficient enriched uranium-235 for one bomb, which became the core of “Little Boy,” the gun-type atomic bomb dropped on Hiroshima on August 6, 1945.

This bomb contained approximately 64 kg of uranium, enriched to about 80% uranium-235.

Upon detonation, it released energy equivalent to 15,000 tons of TNT, obliterating five square miles of the city and killing an estimated 70,000 people instantly.

Three days later, a plutonium bomb called “Fat Man” was dropped on Nagasaki, leading to Japan’s surrender on August 15, 1945, and the conclusion of World War II.

The Y-12 plant had fulfilled its mission, and the Calutrons had proven successful.

However, the aftermath brought a reckoning with the silver.

After the war, the electromagnetic separation process was abandoned in favor of gaseous diffusion, which proved more efficient for large-scale production.

The Calutrons were dismantled, and the magnets disassembled.

The silver needed to be returned.

Every coil was carefully unwound, and every component was disassembled and cleaned.

The silver strips were recovered, weighed, and inventoried.

Workers even ripped up floorboards beneath the machinery and burned them to recover microscopic traces.

Kenneth Nichols was tasked with documenting every troy ounce, and the scrutiny was intense.

Ultimately, out of the 430 million troy ounces loaned, only 155,645.39 troy ounces were lost—less than 0.036%.

The missing silver had been lost to the process, vaporized, chemically bonded, or embedded in materials that could not be recovered.

The Treasury was satisfied; the silver was returned, and the debt was paid.

The last pieces of silver weren’t replaced until May 1970, when the final 67 tons were swapped for copper and returned to the Treasury nearly 30 years after the initial loan.

The story of the Calutron and the silver loan is more than a wartime anecdote; it serves as a testament to what can be achieved when engineers confront impossible problems with limited resources.

The electromagnetic separation principle developed for the Calutron lives on today.

Mass spectrometers utilize the same basic concept Lawrence pioneered, employing ionized particles that pass through magnetic fields to separate them by mass.

These instruments find applications in medical research, environmental monitoring, forensic analysis, and even space exploration.

The Y-12 facility still exists in Oak Ridge, Tennessee, now known as the Y-12 National Security Complex, operated by the Department of Energy’s National Nuclear Security Administration.

While it no longer enriches uranium, it remains responsible for maintaining and producing components for the entire U.S. nuclear arsenal.

This story also illustrates the extraordinary lengths governments will go to secure technological advantages during wartime.

Borrowing 14,700 tons of silver from the nation’s reserves was an act of desperation and faith—faith that the science would work, that the engineering would succeed, and that the investment would yield results.

And indeed, it did.

The tale of the Calutron girls serves as a poignant reminder that history’s great achievements often rest on the shoulders of ordinary people performing extraordinary work, often without recognition.

Those young women at control panels, diligently keeping needles in the green zones, played a role as critical as the scientists who understood the physics.

Execution matters as much as understanding.
